Product Overview

The Manure Spreader For Small Farms is a compact, ground-driven pull implement for spreading livestock manure and compost on small farms and paddocks.

Technical Specifications

Category	Parameter	Specification Value
Capacity & Load	Rated Load Capacity	1,200 kg (approx. 2,640 lbs)
	Heaped Capacity	1.25 m³ (approx. 35 Bushels)
	Struck Capacity	0.85 m³ (approx. 24 Bushels)
Power & Drivetrain	Drive Type	Ground-Driven (Two-wheel traction engage)
	Min. Horsepower Requirement	15 HP (Suitable for ATVs, UTVs, or compact tractors)
	Drivetrain Protection	Shear Bolt & Mechanical Engagement Clutch
Spreading Performance	Spreading Width	1.8 m - 2.5 m (6 ft - 8 ft, depending on ground speed)
	Beater Type	Dual Horizontal Heavy-Duty Steel Beaters
	Feed Rate Control	2-Speed manual traction adjustment for conveyor chain
Structure & Materials	Box Material	3 mm Hot-Dip Galvanized Anti-Corrosion Steel
	Floor Material	12 mm Maintenance-Free High-Density Polyethylene (HDPE)
	Conveyor Chain Spec	High-Tensile T-Rod Apron Chain
Dimensions & Mobility	Overall Dimensions (L×W×H)	2,850 × 1,350 × 1,050 mm (approx. 112 × 53 × 41 in)
	Box Inside Dimensions (L×W×H)	1,750 × 950 × 600 mm (approx. 69 × 37 × 24 in)
	Empty Weight	320 kg (approx. 705 lbs)
	Tyre Size	22 × 11.00-8 High-Flotation Agricultural Tyres
	Hitch Type	Standard Drop-Pin Tow Hitch

Manufacturing Capabilities & QC

Manufacturing Capabilities

Laser Cutting & CNC Bending

Automated fabrication ensures dimensional consistency for structural steel frames.

Robotic Welded Box Joints

Continuous automated welding supports structural strength for agricultural equipment.

Hot-Dip Galvanizing Lines

In-house zinc baths provide corrosion-resistant coatings for agricultural environments.

Quality Control

Weld Penetration UT Testing

Ultrasonic testing checks structural joints for internal weld flaws or voids.

Dynamic Beater Balancing

High-speed rotational balancing reduces vibration in the beater assembly.

Pre-Shipment Run Test

Functional testing verifies conveyor chain alignment and mechanical clutch engagement.

Standards & Certifications

Standard / Certification	Description
ASABE S318 Standard	Conformance to safety standards for agricultural field equipment.
ISO 9001:2015 Certification	Certified manufacturing facilities govern the agricultural implement production processes.
CE Machinery Directive 2006/42/EC	Compliant with directives for towed agricultural machinery distribution.

OEM, ODM & Logistics Support

OEM & ODM Support
Custom Brand Labeling: Private label options include powder-coat color matching and decal application.

Chassis & Hitch Adaptations: Engineering adjustments modify tongue lengths and hitch interfaces to meet regional towing standards.

Component Substitution Options: Capacity for alternative tire profiles, floor thicknesses, or chain configurations per specification.

Logistics Support
SKD/CKD Shipping Configurations: Semi-knocked down or completely knocked down packaging improves container space utilization.

Steel-Crated Packaging: Steel crates p0072otect structural components and drive mechanisms during transit.

ISPM 15 Compliant Pallets: All wooden packaging elements undergo certified heat treatment for international customs clearance.

Applications

Application	Material & Usage	Benefits
Equine Facilities	Spreading bedded horse manure across exercise paddocks.	Supports manure distribution across paddock areas.
Organic Vegetable Farms	Distributing composted manure between raised planting rows.	Suitable for applying composted manure between planting rows.
Small-Scale Orchards	Applying aged poultry litter under fruit tree canopies.	Suitable for applying aged poultry litter around tree rows.
Rotational Pastures	Top-dressing grazed paddocks with livestock manure during rotation.	Used for manure application during pasture rotation.

Warranty, Parts & Technical Support

Warranty & Parts

Limited Structural Coverage

A designated multi-year warranty covers the main chassis frame and box assembly.

Wear Parts Availability

Replacement gears, sprockets, chains, and shear bolts are available for shipment.

Technical Support

Exploded-View Manuals

Detailed parts books and schematics support parts identification and field maintenance.

Video Maintenance Guides

Video tutorials demonstrate drive chain tensioning and bearing lubrication procedures.

FAQ

Q: What types of agricultural waste can this equipment handle efficiently?

A: It processes semi-solid livestock manure, bedded straw mixtures, and composted organic materials of various moisture levels.

Q: How often should the mechanical drive chain be lubricated?

A: Lubrication with standard agricultural chain lube is recommended after every thirty hours of operational field use.

Q: Can the unit be towed safely by an ordinary utility terrain vehicle (UTV)?

A: Yes, provided the towing vehicle possesses sufficient braking capacity and a standard drop-pin hitch receiver.

Q: How do you prevent rust during sea freight and ocean shipping?

A: The chassis is hot-dip galvanized. Moving parts receive anti-rust oil, and the unit is packed with moisture-absorbing desiccant.
